Water Cooling UV LED Curing Light 160x30mm 18W/CM2 395nm UV LED Array Lamp

Gambar besar : Water Cooling UV LED Curing Light 160x30mm 18W/CM2 395nm UV LED Array Lamp

Detail produk:

Tempat asal:	CINA
Nama merek:	CG
Sertifikasi:	CE*RoHS
Nomor model:	CG-CT3-40027-1500A/C

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1set
Harga:	2000-2200usd 1 set
Kemasan rincian:	Kasing kayu
Waktu pengiriman:	10-15 hari kerja
Syarat-syarat pembayaran:	L/c, t/t
Menyediakan kemampuan:	10 set/hari

Kontak

Water Cooling UV LED Curing Light 160x30mm 18W/CM2 395nm UV LED Array Lamp

Deskripsi

kata kunci:	Sistem Penyembuhan UV LED	Kekuatan:	1200W
Tegangan input:	AC85-265V	Panjang gelombang:	395nm
Cara pendingin:	Pendingin air	Intensitas UV:	18W/CM2
Jaminan:	2 tahun	Kemasan:	Kasing kayu
Menyoroti:	UV LED curing light 18W/CM2 , Water cooling UV LED lamp 395nm , 160x30mm UV LED array curing system

Water Cooling 160*30mm 18W/CM2 395nm UV LED Array Lamp

LED UV Curing System Description

The "LED" UV curing lamp is an innovative technology that uses ultraviolet radiation to rapidly dry UV-based materials such as resin, ink, varnish, adhesive, and coatings, offering excellent performance and efficiency in today's applications.

LED UV Curing System Datasheet

Model	CG-CT3-40027-1200A	lamp color	Rose golden
Power	1200W	Chip brand	LG/Seoul
Input voltage	AC85-265V	Wave length	365/385/395/405nm
Application	UV ink/vanish/coating /adhesive curing	Life span	20000H
Cooling way	Water cooling	Emitting window size	customized
UV intensity	18W/CM2	Dimmable	0%-100%
Best emitting distance	30-50mm	Package	wooden case

Water Cooling UV LED Curing Light 160x30mm 18W/CM2 395nm UV LED Array Lamp 0

LED UV Curing System Advantages

Energy-efficient: Typically, a 1000W LED UV lamp provides the same drying effect as a 6000W mercury vapor lamp.
Eco-friendly: Contains no mercury, and does not produce ozone or release VOCs.
Instant operation: No warm-up time required, can be turned on and off immediately.
Low heat emission: Suitable for curing PE and film inks.
Durable: Has a long lifespan of up to 20,000 hours.

LED UV Curing System FAQ:

Q1: What’s the wavelength of the leduv lamp ?

A1: Usually 395-405nm The 395nm/385nm is used for printing machine ,365 nm is for adhesive.

Q2: What’s your led brand ?

A2:LG/Seoul

Q3: What’s the material of lamp and lens ?

A3: Aluminium /quartz

Q4: What’s the cooling way for the leduv curing system ?

A4: Water or air cooling

Q5: The uv intensity can be change?

A5: Yes, the uv intensity is changeable from 0%-100%

Q6: What’s the max energy of uvled lamp ?

A6: It’s depend on emitting time , the longer the higher energy output total amount.

Q7: What’s the lifespan of the uvled curing lamp ?

A7: Our warranty is 2yeas for all system (Chiller /power supply ) mostly can reach 5yeas
